Horizontale Drehmaschine DMG MORI CLX 450

- Manufacturer: DMG MORI
- Model: CLX 450
- Type of machine: Horizontal Turning Machine
- Year: 2020
- Max Spindle Speed: 4000 RPM
- Weight: 6400 kg
- Power Requirements:
- Power: 39 kVA
- Max Current: 56 A
- Max Voltage: 440 V ±10%
- Frequency: 50/60 Hz
- AC Voltage: 400 V
- DC Voltage: 24 V

Including the following equipment:

- 13 rotary tool holders (coolant through, 5 radial and 8 face) by ALGRA/MT Marchetti
- more than 20 steady tool holders for turning and boring tools by ALGRA
- 4 bolted tool holders by SAUTER/ALGRA
- a mechanically operated bar puller toolholder by KINTEK
- a live center
- balanced pressure clamping (able to grip thin walled parts)
- sets plastic drawtubes for bar working in different diametrers
- more than 50 sets of soft machined jaws
- 5 sets of hard jaws for different range of diameters and inside/outside clamping by SMW
- SMW special ring for soft jaw turning/machining
