Spritzgiessmaschinen ENGEL Victory 650-120 Tech

warehouse no.: 503240
manufacturer: ENGEL
type: Victory 650-120 Tech EC200 A02
year of construction: 2008
operation hours: 60000 h

clamping force: 1200 kN
size of mould plates h x v: 740 x 680 mm
min. mould height: 300 mm
max. open daylight: 800 mm
opening stroke: 500 mm

screw diameter: 45 mm
swept volume: 318 ccm
injection pressure: 1232 bar

equipment included:
screen text german
CEE-socket 16A
core pulling hydraulically 2x
air valve 1x
machine incl. water flow regulator
machine without material hopper
Anti vibration mounts
interface EUROMAP 67
mould heating 8x

measures of machine lxbxh: 4.86m x 1.5m x 2.1m
total weight: 7600KG
Verkäufer Angebot Nr. resale 503240
