CNC Bearbeitungszentren FANUC robocut

x-Weg:370 mm

y-Weg:270 mm

z-Weg:254 mm

Machine-Details
Stock-No. 1105-03942
Type of machine Wire Eroding Machine
Make FANUC
Type Robocut Alpha oid
Year of manufacture 2008
Type of control CNC
Storage location FRANKREICH
Country of origin JAPAN
Delivery time to be agreed
Freight basis ex site
Price

Technical details
table length 700 mm
table width 400 mm
control fanuc 310 s wa
x-axis 520 mm
y-axis 370 mm
U-axis +/- 60 mm
V-axis +/- 60 mm
Konikangle (100mm) +/- 30 °
z-axis 410 mm
max. workpiece sizes 600 x 420 mm
max. workpiece height 400 mm
max. workpiece weight 400 kg
rapid traverse 0,9 m/min
interval size of the actuator 0,001 mm
wire dia. 0,1 - 0,30 mm
wire speed 0 - 15 m/min
wire clamping 200 - 2.500 g
total power requirement ~ 14 kVA
weight of the machine ca. 2,5 t
dimensions of the machine ca. 3,2 x 2,5 x 2,1 m
Accessories
Documents
elektr. hand wheel
Verkäufer Angebot Nr. resale 162704649
